Power sonic密封鉛酸電池PS-12800
地區(qū)城市：廣東省 －深圳市 遵義市 貴陽市 更新時間：2014-7-9 10:20:07
聯(lián) 系 人： 鄭偉 有效期限：2015-7-9 10:09:18
公司名稱：深圳市凱薩電子有限公司
電子信箱：sdshwzheng@live.com 聯(lián)系電話：0755-61283162-802
Performance Specifi cations
Nominal Voltage ........................................................................ 12 volts (6 cells)
Nominal Capacity
20-hr. (115mA to 10.50 volts) ........................................................ 2.30 AH
10-hr. (225mA to 10.50 volts) ....................................................... 2.25 AH
5-hr. (390mA to 10.20 volts) ....................................................... 1.95 AH
1-hr. (1.38A to 9.00 volts) ............................................................ 1.38 AH
15-min. (4.5A to 9.00 volts) .................................................................1.13 AH
Approximate Weight ........................................................... 1.70 lbs. (0.77 kg)
Energy Density (20-hr. rate) ............................... 1.71 W-h/in3 (104.12 W-h/l)
Specifi c Energy (20-hr. rate) .............................. 16.24 W-h/lb (35.79 W-h/kg)
Internal Resistance (approx.) ..... This battery is protected by a bimetal circuit
breaker. If the current discharge temperature
rises above design limits the breaker is activated
Max Discharge Current (7 Min.) .................................................. 6.9 amperes
Max Short-Duration Discharge Current (10 Sec.) ....... n/a - battery is fused
Shelf Life (% of nominal capacity at 68°F (20°C))
1 Month ...................................................................................................... 97%
3 Months ..................................................................................................... 91%
6 Months .................................................................................................... 83%
Operating Temperature Range
Charge .. .......................................................... 15°F (-10°C) to 105°F (40°C)
Discharge ........................................................ 15°F (-10°C) to 105°F (40°C)
Case ...................................................................................................... ABS Plastic
Power-Sonic Chargers ................................................................... PSC-12300A
