輸入/輸出規(guī)格參數[Input/Output Specifications]:

         輸入電壓[Input Voltage]:                          AC 100-240V,50/60Hz

         輸出功率[Output Power]:                           24W

         輸出電壓[Output Voltage]:                         3V-36V

         輸出電流[Output current]                          0.1A-2A

         過壓保護[Over Voltage Protection]:                120%min

         過流保護[Over Current Protection]:                120%min

         短路保護[Short Protection]:                       Auto Recove

輸出電壓變動[Load Regulation]:                     ±5%

一般參數規(guī)格[General Specifications]

         工作環(huán)境溫度[Operating Temperature]:              0~40℃

         儲存溫度[Storage Temperature]:                    -20~85℃

         工作溫度[Operating Relative Humidity]:            5~95%RH

         耐壓[Withstanding Voltage]:                       AC 2000V(Min),5mA(Max)

         絕緣抗體[Insulation Resistance]:                  DC 500V  100MΩ(Min)

用途[Application]:

        電腦.安防 監(jiān)控.儀表 儀器.數碼相框.

音響 多媒體產品.燈飾.電話機.按摩器.

電池充電器.交換機.玩具 .LED產品.通訊產品等等
