No.

Item

Performance

1

使用溫度范圍

Operating Temperature Range

-40℃ to +105℃

2

定格電壓范圍

Rated Working Voltage Range

6.3-100V.DC

3

靜電容量范圍

Capacitance Tolerance

0.47－15000µF

4

靜電容量容許差

Capacitance Tolerance

±20% (at+25℃,120Hz)

5

泄漏電流

Leakage Current

I≤0.02CV（µA） or4（µA） after one minutes

6

損失角

Dissipation Factor(tanδ)

（120Hz\+25℃）

For capacitance value ＞1000µF, add 0.02 per another 1000µF

7

溫度特性（at  120  Hz）

Characteristics at low temperature （stability at 120Hz）

8

高溫負荷特性

High Temperature Loading

After 3000 hrs. application of DC rated working voltage at +105℃,The capacitor shall meet the following limits: Post test requirements at + 25℃

9

高溫無負荷特性

Shelf Life

After storage for 500hrs. at+105℃ with no voltage applied.

Post test requirements at+25℃

Same limits for high temperature lading.
